The TLV70028EVM-463 from Texas Instruments is a state-of-the-art evaluation module designed to help engineers and developers test the performance and functionality of the TLV70028 low-dropout regulator (LDO). This robust evaluation module is an essential tool for anyone looking to incorporate the TLV70028 LDO into their power management solutions.

Key Features

• High Accuracy: The TLV70028EVM-463 delivers a fixed output voltage with high accuracy, ensuring reliable and consistent performance for sensitive electronic applications.
• Low Dropout: With its low-dropout feature, the module operates efficiently even when the input voltage is close to the output voltage, minimizing power loss and enhancing system efficiency.
• Thermal Protection: The module includes built-in thermal shutdown and current limit features to protect the LDO and the application from damage due to overheating or overcurrent conditions.
• Easy-to-Use: Designed with simplicity in mind, the TLV70028EVM-463 comes with user-friendly connectors and test points, making it easy to integrate into a variety of test setups.
• Flexible Applications: The evaluation module is suitable for a wide range of applications, including wireless handsets, portable media players, and other portable electronics that require a stable and efficient power supply.

Technical Specifications

• Fixed Output Voltage: 2.8V
• Maximum Output Current: 200 mA
• Input Voltage Range: 2.0V to 5.5V
• Thermal Protection and Current Limit
• Low Quiescent Current
• Stable with Low ESR Capacitors

Package Contents

The TLV70028EVM-463 package includes the evaluation module board pre-assembled with the TLV70028 LDO, a user's guide, and additional supporting documentation to assist with setup and analysis. Engineers can quickly set up the board and start evaluating the LDO's capabilities in their specific applications.

Getting Started

To begin using the TLV70028EVM-463, simply apply the appropriate input voltage, connect the load, and observe the performance of the LDO. The evaluation module's comprehensive documentation provides detailed instructions and guidance for conducting various tests and measurements to thoroughly assess the LDO's performance in real-world scenarios.
