Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Simple Reset/Power-On Reset
Number of Voltages Monitored 1
Output Push-Pull, Totem Pole
Reset Active High/Active Low
Reset Timeout 1.1 ms Minimum
Voltage - Threshold 2.93V
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 081478-TLC7733ID
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Medical, Imaging, Video & Vision, Computers & Computer Peripherals
Ultra Librarian 3D Model Ultra Librarian TLC7733ID CAD Model

Description

Overview of Texas Instruments TLC7733ID Voltage Supervisor

The Texas Instruments TLC7733ID is a precision supply voltage supervisor designed to monitor VCC in digital systems and provide a reset signal to the host processor when necessary. This device helps to ensure that the system boots up in a predictable state every time it is powered on or when there is a drop in the supply voltage below a designated threshold, known as the reset threshold voltage.

Key Features

  • Programmable Reset Delay: The TLC7733ID comes with an externally programmable delay time for the reset signal, providing flexibility to suit various system requirements.
  • Low Supply Current: With a typical supply current of 15 µA, this voltage supervisor is an energy-efficient solution for power-conscious applications.
  • High Accuracy: The device features a precision voltage sensor, which is critical for reliable operation of microprocessors and other digital systems.
  • Wide Operating Range: The TLC7733ID operates over a range of 1.1 V to 5.5 V, accommodating a variety of digital circuits and systems.
  • Active-Low Reset: It provides an active-low reset signal, which is a common requirement for interfacing with a multitude of microprocessors and digital ICs.

Applications

The TLC7733ID is suitable for a wide range of applications that require voltage supervision, including:

  • Microprocessor, microcontroller, or DSP systems
  • Portable/battery-powered equipment
  • Intelligent instruments
  • Industrial controls
  • Automotive systems

Package and Quality

This voltage supervisor comes in an 8-pin SOIC package, which is compact and suitable for surface-mount technology (SMT). Texas Instruments ensures high-quality standards, making the TLC7733ID a reliable choice for critical applications where system stability is paramount.

By integrating the TLC7733ID into your system, you can enhance the reliability and robustness of your digital systems, ensuring they operate correctly following power-up or during undesirable voltage fluctuations.
