SN65LVDS2DBVT Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Receiver
Protocol LVDS
Number of Drivers/Receivers 0/1
Data Rate 400Mbps
Supply Voltage - Operating 2.4 V to 3.6 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package SOT-23-5
Win Source Part Number 029583-SN65LVDS2DBVT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian SN65LVDS2DBVT CAD Model

Description

The SN65LVDS2DBVT from Texas Instruments is a cutting-edge, high-performance differential line receiver that implements the electrical characteristics of low-voltage differential signaling (LVDS).

  • Data Transfer Speed: Up to 630 Mbps
  • Temperature Range: -40°C to 85°C
  • Supply Voltage Range: 2.7V to 3.6V
  • Power Consumption: 1.25 mW @ 200 Mbps
  • Fail-Safe Feature: Guarantees a high output level when the inputs are left open, shorted, or terminated but not driven
  • Pinout: Flow-through
  • Package: 8-pin SOIC
