The REF5040AIDGKR is a high-precision, low-noise, low-drift voltage reference from Texas Instruments, designed to maintain accurate voltage regulation across a wide range of operating conditions. This device is particularly well-suited for high-end instrumentation, precision data acquisition systems, and industrial applications requiring a stable reference voltage over time and temperature.

Key Features

• Precision Voltage: The REF5040AIDGKR offers a fixed 4.096V output with an impressive initial accuracy of ±0.05%.
• Low Temperature Drift: With a temperature drift of just 3ppm/°C, users can rely on stable performance across a temperature range of -40°C to +125°C.
• Low Noise: It exhibits an exceptionally low noise performance of 8µVpp/V, which is critical for high-precision applications.
• High Output Current: This device can source up to 10mA and sink up to -5mA, providing flexible load-driving capabilities.
• Long-Term Stability: A typical long-term stability of 50ppm/1000 hours ensures reliability and consistency in performance over time.
• Small Package: The REF5040AIDGKR comes in an ultra-small MSOP-8 (DGK) package, which is ideal for space-constrained applications.

Applications

With its high accuracy and stability, the REF5040AIDGKR is an excellent choice for a variety of applications, including:

• Precision Analog-to-Digital Converters (ADCs)
• Digital-to-Analog Converters (DACs)
• Portable Instrumentation
• Medical Equipment
• Industrial Process Control Systems
• Battery-Powered Devices

Quality and Support

Texas Instruments is known for its commitment to quality and reliability. The REF5040AIDGKR is backed by extensive testing and validation to meet the stringent requirements of industrial and precision applications. Technical support and comprehensive documentation are available to assist with design and integration challenges.
