Same model may have multiple batches, images only for reference.

RC4580IDR

Name: RC4580IDR
Brand: Texas Instruments
SKU: 291167
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	RC4580IDR
Manufacturer	Texas Instruments
Catalog	Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description	IC OPAMP AUDIO 12MHZ 8SOIC
Datasheet	RC4580IDR Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Texas Instruments
Packaging	Reel - TR
Status	Active
Amplifier Type	Audio
Number of Circuits	2
Slew Rate	5 V/μs
Gain Bandwidth Product (GBP)	12MHz
Current - Input Bias	100nA
Voltage - Input Offset	500μV
Operating Supply Current	6mA
Channel Output Current	50mA
Supply Voltage - Operating	4 V to 32 V, ±2 V to 16 V
Temperature Range - Operating	-40°C to 85°C
Mounting	SMD (SMT)
Case / Package	8-SOIC
Win Source Part Number	027221-RC4580IDR
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Family Name	RC4580
Introduction Date	September 01, 2005
ECCN	EAR99
Country of Origin	Malaysia, Malaysia, Mexico, Mexico
Halogen Free	Compliant
Estimated EOL Date	2028
Ultra Librarian 3D Model	Ultra Librarian RC4580IDR CAD Model

Alternative Products

Description

The RC4580IDR is a high-performance, dual operational amplifier product from Texas Instruments, a renowned global semiconductor design and manufacturing company.

Supply Range: ±2.5V to ±18V
Temperature Range: -40°C to +85°C
Unity Gain Bandwidth: 10MHz
Slew Rate: 5.5V/µs
Total Harmonic Distortion plus Noise (THD+N): 0.0005% @ 1kHz
Noise Density: 10nV/√Hz @ 1kHz
Input Bias Current: 500nA
Input Offset Voltage: 3mV
Package: Compact 8-pin SOIC package
Features: Short-circuit protection and thermal shutdown
