Products specifications Report Issue?

Manufacturer Texas Instruments
Packaging Tray
Type Non-Isolated PoL Module
Number of Outputs 1
Voltage - Input (Min) 2.95V
Maximum Input Voltage 3.65V
Voltage - Output 1 0.55 ~ 1.8V
Current - Output (Maximum) 10A
Applications ITE (Commercial)
Features Remote On/Off, OCP, UVLO
Temperature Range - Operating -40°C ~ 85°C
Efficiency 86%
Mounting Style SMD
Manufacturer Package 10-SMD Module
Dimension 0.99" L x 0.62" W x 0.38" H (25.3mm x 15.8mm x 9.6mm)
Part Number Series PTH03060Y
Manufacturer Pack Quantity 36
MSL Level 3 (168 Hours)
Popularity Low
Supply and Demand Status Limited
Win Source Part Number 813778-PTH03060YAZ
Ultra Librarian 3D Model Ultra Librarian PTH03060YAZ CAD Model

Description

Product Overview: PTH03060YAZ from Texas Instruments

The PTH03060YAZ is a high-performance, non-isolated module power converter from Texas Instruments (TI), one of the leading manufacturers in the semiconductor industry. This power module is part of TI's extensive range of power management solutions designed to cater to a wide array of applications that require efficient and reliable voltage conversion.

Key Features

  • Wide Input Voltage Range: The PTH03060YAZ operates with an input voltage range of 2.95V to 3.65V, making it suitable for applications that utilize a 3.3V nominal input voltage. This feature allows for flexibility in various power supply designs.
  • Adjustable Output Voltage: The output voltage of this module is adjustable from 0.8V to 2.5V, providing versatility for powering a range of devices that require different voltage levels.
  • High-Efficiency: With an efficiency of up to 92%, the PTH03060YAZ ensures minimal power loss during voltage conversion, thus conserving energy and reducing thermal challenges in systems.
  • High Output Current: It is capable of delivering up to 6A of output current, which is sufficient for powering high-performance integrated circuits and other electronic components.
  • Small Footprint: The compact size of the module is ideal for space-constrained applications, allowing designers to maximize space without compromising on power capabilities.
  • Thermal Protection: The PTH03060YAZ includes features such as over-temperature protection, safeguarding the device and the system from potential damage due to excessive heat.

Applications

The PTH03060YAZ is versatile and can be used in a variety of applications, including but not limited to:

  • Telecommunications equipment
  • Networking equipment such as routers and switches
  • Industrial systems
  • Test and measurement devices
  • Computing and data storage systems

With its robust design and high reliability, the PTH03060YAZ from Texas Instruments is a top choice for designers and engineers looking for a power module that can deliver consistent performance in a compact package. Whether for new designs or upgrading existing systems, this power converter module is engineered to meet the rigorous demands of modern electronic devices.
