Products specifications

Categories Power Supplies - Board Mount
Manufacturer Texas Instruments
Series DCH01
Packaging Tray
Type Isolated Module
Number of Outputs 1
Input Voltage MIN 4.5V
Voltage Input MAX 5.5V
Voltage - Output 1 12V
Current - Output (Maximum) 83mA
Power (Watts) 1W
Voltage - Isolation 3kV (3000V)
Applications ITE (Commercial)
Operating Temperature Range -40°C ~ 85°C
Efficiency 74%
Mounting Style Through Hole
Package 7-SIP Module, 4 Leads
Dimension 0.77" L x 0.30" W x 0.40" H (19.6mm x 7.6mm x 10.2mm)
Win Source Part Number 772525-DCH010512SN7
Popularity Medium
Supply and Demand Status Limited
Family Name DCH010512SN7
Introduction Date January 06, 2006
ECCN EAR99
Country of Origin Mexico, United States of America
Halogen Free Not Compliant
Estimated EOL Date 2029
Ultra Librarian 3D Model Ultra Librarian DCH010512SN7 CAD Model

Description

The DCH010512SN7 is a highly reliable, compact DC-DC converter module manufactured by Texas Instruments. This advanced power solution is designed to meet the stringent requirements of a wide range of electronic applications, providing stable and efficient voltage conversion in a miniaturized package.

Key Features

  • Input Voltage Range: The device operates with an input voltage range of 4.5V to 5.5V, making it suitable for 5V supply systems.
  • Output Voltage: This model provides a 12V output, which is essential for systems that require a regulated 12V rail.
  • High Efficiency: With an efficiency rate that can reach up to 85%, the DCH010512SN7 ensures minimal power loss during the voltage conversion process.
  • Isolation: The converter offers 1kVDC isolation, providing protection against high voltage spikes and enhancing system reliability.
  • Compact Size: Its small footprint makes it an ideal choice for space-constrained applications, without compromising on performance.
  • Industry Standards: The module complies with industry standards, ensuring compatibility and ease of integration into various designs.

Applications

The DCH010512SN7 is versatile and can be used in a multitude of applications, including but not limited to:

  • Industrial control systems
  • Data communication equipment
  • Telecommunication devices
  • Mixed-signal applications (combining analog and digital circuits)

Quality and Reliability

Texas Instruments is renowned for its commitment to quality and the DCH010512SN7 is no exception. It undergoes rigorous testing to ensure it meets high-quality standards, offering dependable performance and longevity. This product's reliability makes it a preferred choice for engineers and designers looking for a DC-DC converter that they can trust to perform consistently over time.

Part Number: DCH010512SN7

Manufacturer: Texas Instruments
