Products specifications Report Issue?

Categories Development Boards, Kits, Programmers
Manufacturer Texas Instruments
Series Boomer
Part Status Obsolete(EOL)
Amplifier Type Class AB
Output Type 1-Channel (Mono) with Mono Headphones
Max Output Power x Channels @ Load 1W x 1 @ 8 Ohm; 90mW x 1 @ 32 Ohm
Operating Supply Voltage 2.2 V ~ 5.5 V
Board Type Fully Populated
Utilized IC / Part LM4892
Supplied Contents Board(s)
Win Source Part Number 779259-LM4892MMBD
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LM4892MMBD CAD Model

Description

LM4892MMBD Audio Power Amplifier

The LM4892MMBD from Texas Instruments is a versatile and high-performance audio power amplifier designed to deliver exceptional sound quality and reliability for a wide range of applications. This compact, yet powerful, surface-mount device is ideal for portable electronic devices where space is at a premium and power efficiency is crucial.

With an output power capability of 1 Watt, the LM4892MMBD can drive a 8Ω load without the need for an external heat sink when playing music or other audio content. It operates on a supply voltage range from 2.2V to 5.5V, making it compatible with most of the low-voltage applications prevalent in modern electronics. The device also features a low quiescent current, which helps to extend battery life in portable applications.

One of the key features of the LM4892MMBD is its "Unity-Gain Stable" design, which allows external gain configuration without the risk of instability. This flexibility enables designers to tailor the gain setting to specific application requirements. Additionally, the amplifier incorporates Texas Instruments' patented "pop & click" noise reduction circuitry, which minimizes noise typically heard during power-up or shutdown transitions.

For ease of use, the LM4892MMBD includes a shutdown mode that can be activated via a logic control signal, reducing the supply current to less than 0.7µA. This feature is especially useful for battery-powered devices, where conserving energy is critical. Moreover, the device's excellent power supply rejection ratio (PSRR) ensures stable operation even in the presence of supply voltage variations, which is common in battery-operated electronics.

Whether used in mobile phones, portable media players, or other handheld devices, the LM4892MMBD from Texas Instruments stands out as a high-quality, efficient solution for portable audio amplification. Its small form factor, low power consumption, and robust feature set make it an excellent choice for designers looking to enhance the audio performance of their products.

Texas Instruments LM4892MMBD LM4892MMBD Product Page
