Products specifications Report Issue?

Categories Development Boards, Kits, Programmers
Manufacturer Texas Instruments
Series Boomer
Part Status Obsolete(EOL)
Amplifier Type Class D
Output Type 2-Channel (Stereo) with Stereo Headphones
Max Output Power x Channels @ Load 2.5W x 2 @ 4 Ohm
Operating Supply Voltage 2.7 V ~ 5.5 V
Board Type Fully Populated
Utilized IC / Part LM49450
Supplied Contents Board(s)
Win Source Part Number 779284-LM49450SQEVAL
Popularity Medium
Supply and Demand Status Limited
Family Name LM49450SQEVAL
Introduction Date February 14, 2008
ECCN EAR99
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian LM49450SQEVAL CAD Model

Description

The LM49450SQEVAL from Texas Instruments is a comprehensive evaluation platform designed for the LM49450, a fully integrated audio subsystem designed for portable handheld applications. This evaluation board facilitates the testing and development of various features of the LM49450, which combines a high-quality I2S input stereo DAC, a mono Class D speaker amplifier, and a DirectPath™ stereo headphone amplifier in a single device.

Key Features

  • Integrated Audio Subsystem: The LM49450 integrates multiple audio functions to reduce component count and design complexity.
  • High-Quality Audio: With an I2S input stereo DAC, the evaluation board delivers high-fidelity audio playback, making it ideal for applications requiring excellent sound quality.
  • Efficient Power Use: The mono Class D speaker amplifier offers high power efficiency, which is crucial for battery-powered devices.
  • Flexible Headphone Support: The DirectPath™ headphone amplifier provides a clear, noise-free audio path for stereo headphone playback.

Application Areas

The LM49450SQEVAL is suitable for a wide range of applications where space and power efficiency are critical. These applications include:

  • Smartphones
  • Tablets
  • Portable media players
  • Handheld gaming devices
  • Other portable electronics

Design Support

Texas Instruments provides extensive design support for the LM49450SQEVAL, including detailed documentation, reference designs, and technical support from TI's engineering community. This ensures that developers have the resources they need to incorporate the LM49450 into their designs effectively.

Easy to Use

The LM49450SQEVAL is designed for ease of use, allowing designers to quickly evaluate the LM49450's features and performance. The board includes all necessary connectors and can be powered through a standard USB interface, making it a versatile tool for rapid prototyping and testing.
