786555-7 Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Manufacturer TE Connectivity AMP Connectors
Packaging Tube
Connector Style D-Type
Connector Type Receptacle, Female Sockets
Number of Positions 68
Number of Rows 2
Shell Size, Connector Layout 0.050 Pitch x 0.100 Row to Row
Contact Type Signal
Mounting Style Through Hole
Flange Feature Housing/Shell (4-40)
Termination Press-Fit
Features Shielded
Shell Material, Finish Steel, Nickel Plated
Contact Finish Gold
Material Flammability Rating UL94 V-0
Current Rating (Amps) 1A
Temperature Range - Operating -55°C ~ 105°C
Voltage Rating 30V
Color Black
Dielectric Material Polyphthalamide (PPA)
Contact Material Phosphor Bronze
Manufacturer Pack Quantity 8
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 810550-786555-7
Ultra Librarian 3D Model Ultra Librarian 786555-7 CAD Model

Description

The TE Connectivity AMP Connectors 810550-786555-7 is a 68-position shielded connector from TE Connectivity AMP Connectors with a D-type connector style.

  • Termination: Press-Fit
  • Mounting Type: Through Hole
  • Voltage Rating: 30V
  • Current Rating: 1A
  • Contact Finish: Gold
  • Contact Material: Phosphor Bronze
  • Shell Material: Steel
  • Shell Finish: Nickel Plated
  • Operating Temperature: -55°C to 105°C
