6-103166-3 Real Image 6-103166-3 label picture 6-103166-3 real image
Same model may have multiple batches, images only for reference.
6-103166-3 Real Image 6-103166-3 label picture 6-103166-3 real image
6-103166-3 Real Image 6-103166-3 label picture 6-103166-3 real image
Same model may have multiple batches, images only for reference.

6-103166-3

Part No 6-103166-3
Manufacturer TE Connectivity
Catalog Rectangular Connectors
Description CONN HEADER R/A 30POS 2.54MM / HDR ASSY, MOD II, SHROUDED, 4 SIDES, DBL ROW, .100X.100 RIGHT ANGLE, W/ .025 SQ POSTS
Datasheet
6-103166-3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer TE Connectivity AMP Connectors
Packaging Tray
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 30
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Number of Positions Loaded All
Style Board to Board or Cable
Shrouding Shrouded - 4 Wall
Mounting Style Through Hole, Right Angle
Termination Solder
Fastening Type Detent Lock
Contact Length - Mating 0.318" (8.08mm)
Contact Length - Post 0.135" (3.43mm)
Insulation Height 0.400" (10.16mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 30.0μin (0.76μm)
Contact Finish - Post Tin
Contact Material Phosphor Bronze
Insulation Material Thermoplastic
Temperature Range - Operating -65°C ~ 105°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 3A
Contact Finish Thickness - Post 100.0μin (2.54μm)
Manufacturer Pack Quantity 56
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 809304-6-103166-3
Ultra Librarian 3D Model Ultra Librarian 6-103166-3 CAD Model

Description

The TE Connectivity AMP Connectors 809304-6-103166-3 is a 30-position through-hole, right-angle header connector with male pins.

  • Temperature Range: -65°C to 105°C
  • Insulation: Shrouded-4 wall
  • Package: Tray
  • Voltage Rating: -
  • Flammability Rating: UL94 V-0
  • Pitch-Mating: 0.100" (2.54mm)
  • Row Spacing-Mating: 0.100" (2.54mm)
  • Contact Finish-Mating: Gold (30.0μin (0.76μm))
  • Contact Finish-Post: Tin (100.0μin (2.54μm))
  • Contact Length-Post: 0.135" (3.43mm)
  • Contact Length-Mating: 0.318" (8.08mm)
  • Supply and Demand Status: Limited
  • Manufacturer Pack Quantity: 56
  • ECCN: EAR99
  • MSL Level: 1 (unlimited)
