1393315-9 TE Connectivity
Same model may have multiple batches, images only for reference.

1393315-9

Part No 1393315-9
Manufacturer TE Connectivity
Catalog Automotive Relays
Description RELAY AUTO SPST-NO-DM 130A 24V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays - Automotive Relays
Mfr TE Connectivity AMP Connectors
Series HCR 150
Package Bulk
Product Status Active
Coil Type Non Latching
Coil Voltage 24VDC
Contact Form SPST-NO (DM) (1 Form X)
Contact Rating (Current) 130 A
Switching Voltage 24VDC - Nom
Must Operate Voltage 14.4 VDC
Must Release Voltage 2.4 VDC
Operate Time 25 ms
Release Time 8 ms
Features -
Mounting Type Chassis Mount
Termination Style Screw Terminal
Temperature Range - Operating -40°C ~ 125°C
Contact Material Silver Tin Oxide (AgSnO)
Coil Power 4.1W
Coil Resistance 141 Ohms
Base Product Number 1393315
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8536.41.0050
Win Source Part Number 1373473-1393315-9
Ultra Librarian 3D Model Ultra Librarian 1393315-9 CAD Model

Description

The TE Connectivity AMP Connectors Automotive Relays are reliable and high-performance relays designed for automotive applications.

  • Contact Rating: 130 A
  • Switching Voltage: 24VDC
  • Contact Form: SPST-NO (DM) (1 Form X)
  • Coil Voltage: 24VDC
  • Coil Type: Non-Latching
  • Coil Resistance: 141 Ohms
  • Mounting: Chassis Mountable
  • Temperature Range: -40°C to 125°C
