AZ9711-1A-12DET American Zettler, Inc.
Same model may have multiple batches, images only for reference.

AZ9711-1A-12DET

Part No AZ9711-1A-12DET
Manufacturer American Zettler, Inc.
Catalog Automotive Relays
Description 45A AUTOMOTIVE RELAY
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays - Automotive Relays
Mfr American Zettler, Inc.
Series AZ9711
Package Box
Product Status Active
Coil Type Non Latching
Coil Current 133.3 mA
Coil Voltage 12VDC
Contact Form SPST-NO (1 Form A)
Contact Rating (Current) 45 A
Switching Voltage 150VDC - Max
Must Operate Voltage 6.8 VDC
Must Release Voltage 0.7 VDC
Operate Time 5 ms
Release Time 3 ms
Features Sealed - Fully
Mounting Type Through Hole
Termination Style PC Pin
Temperature Range - Operating -40°C ~ 125°C
Contact Material Silver Tin Oxide (AgSnO)
Coil Power 1.6W
Coil Resistance 90 Ohms
Standard Package 100 pcs
Win Source Part Number 818321-AZ9711-1A-12DET
Ultra Librarian 3D Model Ultra Librarian AZ9711-1A-12DET CAD Model

Description

The 818321-AZ9711-1A-12DET is an automotive relay designed for automotive applications.

  • Series: AZ9711
  • Manufacturer: American Zettler, Inc.
  • Contact Form: SPST-NO (1 Form A)
  • Coil Voltage: 12VDC
  • Contact Rating: 45A
  • Switching Voltage: 150VDC - Max
  • Sealed: Sealed and fully protected
  • Package: Box
  • Standard Package: 100 pieces
  • Temperature Range: -40°C to 125°C
  • Status: Active
  • Warning: California Prop 65
