PH150F485 Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Mounting SMD (SMT)
Case / Package Module
Current - Output 1 30 A
Depth 86 mm
Features OCP, OVP
Height 12.7 mm
Isolation Isolated
Isolation Voltage 3 kV
Length 86.106 mm
Max Input Voltage 76 V
Maximum Operating Temperature 85 °C
Max Output Current 30 A
Max Power Dissipation 150 W
Min Input Voltage 36 V
Min Operating Temperature -20 °C
Mount Through Hole
Number of Outputs 1
Number of Pins 14
Output Current 30 A
Output Power 150 W
Output Voltage 5 V
Packaging Bulk
RoHS Compliant
Voltage - Output 1 5 V
Width 83.058 mm
Win Source Part Number 1017385-PH150F485
Categories Board Mount Modules
Manufacturer TDK-Lambda Americas Inc.
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian PH150F485 CAD Model

Description

The PH150F485 is an electronic component manufactured by TDK-Lambda Americas Inc. and is a part of the Board Mount Modules category.

  • Win Source Part Number: 1017385-PH150F485
  • Supply and Demand Status: shortage
  • Component Type: Isolated DC-DC converter module
  • Output Power: 150W
  • Output Voltage: 5V
  • Protection: Overcurrent protection, overvoltage protection
  • Isolation: 3kV
  • Applications: industrial control systems, telecommunications, and other power conversion devices
  • Package: SMD (SMT)
  • Pins: 14
