The TS20 series from Suntan Capacitors refers to a type of metallized polypropylene film capacitor. These capacitors are commonly used in applications requiring high stability, low loss, and high pulse strength. They are well-suited for demanding circuits where reliability and performance are critical.

Applications:

• Lighting ballasts: Used as DC-linking capacitors in electronic ballasts for fluorescent and LED lighting.
• Power supplies: Employed in switched-mode power supplies (SMPS) for filtering and energy storage.
• Motor run capacitors: Used in single-phase AC motors to provide the necessary phase shift for starting and running the motor.
• Snubber circuits: Suppresses voltage transients in switching circuits to protect power semiconductors.
• Audio equipment: Used in high-end audio amplifiers and crossovers for their low distortion characteristics.

Features:

• Metallized Polypropylene Film: Provides excellent electrical characteristics and long-term stability.
• Self-Healing Properties: The metallization layer can vaporize and isolate small defects, preventing catastrophic failure.
• Low Dissipation Factor (Low ESR): Minimizes energy loss and heat generation.
• High Insulation Resistance: Ensures minimal leakage current.
• High Pulse Strength: Can withstand high voltage and current pulses.

Benefits:

• High Reliability: Provides long-term, dependable performance in demanding applications.
• Excellent Stability: Maintains stable capacitance values over a wide range of temperatures and frequencies.
• Low Losses: Minimizes energy waste and heat generation, improving efficiency.
• Self-Protection: Self-healing properties enhance overall reliability and prevent failures.
• Wide Range of Values: Available in various capacitance and voltage ratings to suit different application needs.

Additional Details:

TS20 series capacitors are available in various lead styles and case sizes to accommodate different mounting requirements. Key specifications include capacitance value, voltage rating, tolerance, operating temperature range, and lead spacing. It's crucial to consult the manufacturer's datasheet for precise electrical characteristics, dimensions, and safety certifications. Proper handling and soldering techniques should be followed to ensure optimal performance and longevity. These capacitors typically meet industry standards such as RoHS and REACH.

The TS20 series offers a robust and reliable solution for applications requiring high-performance film capacitors.
