The STPS30170CG-TR is a cutting-edge power Schottky rectifier designed and manufactured by STMicroelectronics, a global leader in semiconductor solutions. This component is specifically engineered to combine low voltage drop with high surge current capability, making it an ideal choice for high-efficiency power supply applications.

Key Features

• High Junction Temperature: Capable of operating at high temperatures, this rectifier ensures reliability and stability in demanding conditions.
• Low Forward Voltage Drop: The device offers a very low forward voltage drop, which enhances power efficiency and reduces thermal dissipation.
• High Surge Current Capability: Designed to handle high surge currents, making it suitable for applications that experience frequent power surges.
• High Frequency Operation: Its fast switching capabilities make it well-suited for high frequency power converters.

Applications

The STPS30170CG-TR is versatile and can be used in a variety of applications, including:

• Switch Mode Power Supplies (SMPS)
• Power Management Systems
• DC-DC Converters
• Free-Wheeling Diodes
• Reverse Battery Protection
• Automotive Applications

Product Specifications

The STPS30170CG-TR is encapsulated in a TO-263 (D2PAK) package, which is designed for optimal thermal performance and space-saving on the PCB. It has a repetitive peak reverse voltage (VRRM) of 170V and an average forward current (IF(AV)) of 30A, ensuring that it can handle significant power levels. The component is also characterized by a low leakage current and a junction temperature range from -40°C to +175°C, which contributes to its efficiency and reliability.

Quality and Environmental Compliance

STMicroelectronics is committed to environmental sustainability. The STPS30170CG-TR complies with RoHS and REACH regulations, ensuring that it is free from hazardous substances and can be used in environmentally sensitive applications. Additionally, the device is supported by ST's longevity program, guaranteeing availability for extended periods, which is particularly important for industrial and automotive industry clients.
