Products specifications Report Issue?

Category Integrated Circuits (ICs)>Embedded - Microcontrollers
Mfr STMicroelectronics
Series STM8L EnergyLite
Package Tape & Reel (TR)
Core Processor STM8
Core Size 8-Bit
Speed 16MHz
Connectivity I2C, SPI, UART/USART
Peripherals Infrared, POR, PWM, WDT
Number of I/O 30
Program Memory Size 8KB (8K x 8)
Program Memory Type FLASH
EEPROM Size 2K x 8
RAM Size 1.5K x 8
Supply Voltage - Operating 1.65V ~ 3.6V
Oscillator Type Internal
Temperature Range - Operating -40°C ~ 85°C (TA)
Mounting SMD (SMT)
Package / Case 32-LQFP
Supplier Device Package 32-LQFP (7x7)
Base Product Number STM8
Standard Package 2,400
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.31.0001
Win Source Part Number 1262072-STM8L101K3T6TR
Ultra Librarian 3D Model Ultra Librarian STM8L101K3T6TR CAD Model

Description

STM8L101K3T6TR Microcontroller from STMicroelectronics

The STM8L101K3T6TR is a cutting-edge microcontroller product designed by STMicroelectronics, tailored for applications requiring a combination of performance, robustness, and low power consumption. This 8-bit MCU is part of the STM8L low-power family and is built on an advanced proprietary core, delivering efficient processing capabilities for a wide range of embedded applications.

The STM8L101K3T6TR operates at a voltage range from 2.95V to 5.5V, making it suitable for battery-operated devices and applications that require a stable operation under varying power supply conditions. With a maximum CPU frequency of 16 MHz, it provides a balanced trade-off between processing power and energy efficiency.

This microcontroller features 8 KB of Flash program memory, which is ample for small to medium-sized applications. Additionally, it comes with 1 KB of RAM and 256 bytes of EEPROM, which are beneficial for data storage and retention across power cycles without the need for external memory components.

The STM8L101K3T6TR is equipped with a rich set of peripherals, including an advanced control timer, a USART for serial communication, and an I2C interface for connecting to other chips or sensors. It also has an SPI interface for high-speed serial data transfer, making it a versatile choice for interfacing with various peripherals and devices.

A 10-bit analog-to-digital converter (ADC) with up to 5 channels allows the microcontroller to interface with analog sensors and convert their signals for digital processing. For enhanced power saving, the STM8L101K3T6TR features multiple low-power modes, including wait, active-halt, and true low-power halt modes, which are essential for extending battery life in portable devices.

The MCU comes in a compact LQFP32 package, making it suitable for space-constrained applications. It is also characterized by an extended temperature range from -40°C to +85°C, ensuring reliable operation in harsh environmental conditions.

The STM8L101K3T6TR is a robust solution for designers looking to develop low-power consumer electronics, home appliances, industrial control systems, and a variety of other embedded systems that require a small footprint, efficient power usage, and reliable performance.
