Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 51 Weeks
Features dsPIC series Microcontroller IC 16-Bit 40 MIPs 256KB (256K x 8) FLASH 100-TQFP (12x12)
Manufacturer Microchip Technology
Series Automotive, AEC-Q100, dsPIC™ 33F
Package Tray
Core Processor dsPIC
Core Size 16-Bit
Speed 40 MIPs
Connectivity CANbus, I2C, IrDA, LINbus, SPI, UART/USART
Peripherals Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, QEI, WDT
Number of I/O 85
Program Memory Size 256KB (256K x 8)
Program Memory Type FLASH
Supply Voltage 3V ~ 3.6V
Data Converters A/D 24x10/12b
Oscillator Type Internal
Operating Temperature Range -40°C ~ 125°C (TA)
Mounting Surface Mount
Package 100-TQFP
Case / Package 100-TQFP (12x12)
Family Name DSPIC33FJ256MC510
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 3A991A2
HTSUS 8542.31.0001
Quantity per package 119
Popularity High
Supply and Demand Status Balance
Win Source Part Number 917673-DSPIC33FJ256MC510A-E/PT
Ultra Librarian 3D Model Ultra Librarian DSPIC33FJ256MC510A-E/PT CAD Model

Description

Microchip Technology's DSPIC33FJ256MC510A-E/PT Product Overview

The DSPIC33FJ256MC510A-E/PT is a high-performance, 16-bit Digital Signal Controller (DSC) from Microchip Technology, designed to deliver the functionality of a microcontroller with the computational power of a Digital Signal Processor (DSP). This powerful hybrid is ideal for applications that require advanced control algorithms and high-speed data processing, such as motor control, power conversion, and sensor processing.

Key Features

  • Core Performance: The device features a 40 MIPS (million instructions per second) dsPIC core with DSP-enhanced instruction set, providing the computational speed necessary for complex algorithms.
  • Program Memory: It comes with 256 KB of flash memory, offering ample space for application code storage.
  • RAM: The controller is equipped with 30 KB of RAM, allowing for efficient data manipulation and buffer storage.
  • I/O Pins: The device includes 85 input/output pins, giving designers flexibility in interfacing with peripherals and external devices.
  • Advanced Peripherals: Integrated peripherals include PWM outputs, analog-to-digital converters (ADCs), and input capture, which are essential for real-time control applications.
  • Communication Interfaces: Multiple serial communication interfaces are available, such as UART, SPI, and I2C, enabling easy data exchange with other components in the system.
  • Operating Voltage: The DSC operates within a range of 3.0 to 3.6 volts, ensuring compatibility with a variety of power systems and reducing power consumption.
  • Temperature Range: It is designed to operate reliably within an industrial temperature range of -40°C to +125°C.
  • Packaging: The DSPIC33FJ256MC510A-E/PT comes in a 100-pin TQFP (Thin Quad Flat Package), which is suitable for surface-mount technology and helps in saving board space.

Applications

This DSC is versatile and can be employed across a wide range of applications, including but not limited to:

  • Advanced motor control systems
  • Power supply and power management systems
  • Industrial control systems
  • Automotive and transportation
  • Audio applications and signal processing
  • Robotics and automation

The DSPIC33FJ256MC510A-E/PT is a robust and feature-rich digital signal controller that provides engineers with a perfect blend of microcontroller usability and digital signal processing power, enabling the creation of sophisticated and efficient applications across various industries.
