STGD14NC60KT4 - N-Channel IGBT from STMicroelectronics

The STGD14NC60KT4 is a high-performance N-channel IGBT (Insulated Gate Bipolar Transistor) designed and manufactured by STMicroelectronics, a global leader in semiconductor solutions. This IGBT is a part of ST's PowerMESH™ IGBTs series, which are specifically engineered to combine the high efficiency of MOSFETs with the high current and low saturation voltage of bipolar transistors.

Key Features

• High Current Capability: The STGD14NC60KT4 is capable of handling significant current levels, making it suitable for a variety of power applications.
• Low On-Voltage Drop (Vce(on)): This IGBT has a low on-state voltage drop, which improves efficiency by minimizing power dissipation during operation.
• High Switching Speed: The device features high-speed switching performance, which is essential for reducing switching losses in high-frequency applications.
• Enhanced Ruggedness: The IGBT is designed to withstand harsh operating conditions, ensuring reliability and longevity in demanding environments.
• Co-Packaged with Free Wheeling Diode: The STGD14NC60KT4 comes with an integrated fast recovery diode, which provides protection against reverse voltage transients and simplifies circuit design.

Applications

The STGD14NC60KT4 is versatile and can be used in a wide array of applications, including:

• Switching power supplies
• Motor control systems
• Power inverters
• Power factor correction circuits
• Induction heating
• Uninterruptible power supplies (UPS)

Technical Specifications

• Collector-Emitter Voltage (Vces): 600V
• Collector Current (Ic): 14A
• Power Dissipation (Pd): 30W
• Operating Junction Temperature (Tj): -55°C to +150°C
• Package: DPAK (TO-252)

The STGD14NC60KT4 IGBT is a testament to STMicroelectronics' commitment to providing innovative, high-performance semiconductor technologies. With its robust design and advanced features, this IGBT is an excellent choice for designers seeking to enhance the efficiency and reliability of their power management systems.
