L6924D013TR

Part No L6924D013TR
Manufacturer STMicroelectronics
Catalog PMIC - Battery Chargers
Description IC BATT CHRGR ION/POLY 16-VFQFPN
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Battery Chemistry Lithium-Ion/Polymer
Number of Cells 1
Current - Charging Constant - Programmable
Programmable Features Current, Timer
Fault Protection Over Temperature
Charge Current - Max 1A
Battery Pack Voltage 4.2V
Maximum Supply Voltage 12V
Temperature Range - Operating -40°C to 125°C (TJ)
Case / Package 16-VFQFP-N (3x3)
Win Source Part Number 113235-L6924D013TR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name L6924D
Introduction Date Mar 8, 2005
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian L6924D013TR CAD Model

Description

STMicroelectronics L6924D013TR Battery Charger IC

The L6924D013TR from STMicroelectronics is a highly integrated and versatile battery charger IC designed for single-cell Li-ion and Li-polymer batteries. It's a perfect solution for portable applications due to its compactness and features that enable efficient charging and power management.

Key Features

  • Adaptive Charge Management: The L6924D013TR adapts the charge cycle to the conditions of the battery, enhancing battery life and performance.
  • Programmable Charging Parameters: Users can program parameters such as pre-charge current, fast charge current, and charge termination threshold, providing flexibility for different battery specifications.
  • High Efficiency: With its switching power supply based design, the IC ensures efficient power conversion, which is crucial for portable devices to maximize battery life.
  • Thermal Protection: The device includes temperature monitoring to prevent overheating during the charging process, ensuring safe operation and preserving the integrity of the battery.
  • Charge Status Indication: The L6924D013TR provides real-time charge status through its multifunctional pins, which can be connected to LEDs or communicated to a microcontroller.

Applications

This versatile charger IC is suitable for a wide range of portable applications, including:

  • Smartphones and tablets
  • Bluetooth headsets
  • Wearable devices
  • GPS units
  • Digital cameras

Package and Availability

The L6924D013TR is offered in a compact VFQFPN-10 package, which minimizes the space required on the PCB and is ideal for space-constrained applications. The device is available in tape and reel packaging, facilitating the manufacturing process for high-volume production.

With its advanced features and flexible programmability, the STMicroelectronics L6924D013TR Battery Charger IC stands out as a robust solution for modern portable electronic devices that demand efficient and reliable battery management.
