KA3010D Real Image
Same model may have multiple batches, images only for reference.

KA3010D

Part No KA3010D
Manufacturer SRA Soldering Products
Catalog Equipment - Power Supplies (Test, Bench)
Description KA3010D - PRECISION VARIABLE ADJ
Datasheet
KA3010D Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Test and Measurement - Power Supplies (Test, Bench)
Mfr SRA Soldering Products
Series Korad
Package Box
Product Status Active
Type Bench (AC to DC)
Voltage - Supply 110 ~ 220VAC
Number of Outputs 1
Voltage - Output 0 ~ 30VDC
Current - Output 0 ~ 10A
Display Type LED
Number of Characters 4 (2)
Size / Dimension 10.240" L x 6.142" W x 4.331" H (260.00mm x 156.00mm x 110.00mm)
Features Adjustable or Fixed Selection Switch, Regulated
Accuracy - Voltmeter; Ammeter 0.5% + 20mV; 0.5% + 20mA
Voltage Regulation - Line 0.01% + 3mV
Voltage Regulation - Load 0.01% + 3mV
Current Regulation - Line 0.1% + 3mA
Current Regulation - Load 0.1% + 20mA
Ripple 2mV rms, 5mV rms
Standard Package 1 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.9530
Win Source Part Number 168351-KA3010D
Ultra Librarian 3D Model Ultra Librarian KA3010D CAD Model

Description

The 168351-KA3010D is a bench power supply from the Korad series.

  • Type: AC to DC converter
  • Selection Switch: Adjustable or fixed
  • Output: Regulated
  • Package: Box
  • Dimensions: 10.240" L x 6.142" W x 4.331" H (260.00mm x 156.00mm x 110.00mm)
  • Output Count: Single
  • Voltage Range: 0 ~ 30VDC
  • Current Range: 0 ~ 10A
  • Ripple: Low ripple with a value of 2mV rms and 5mV rms
  • Display: LED with 4 characters (2)
  • Voltmeter Accuracy: 0.5% + 20mV
  • Ammeter Accuracy: 0.5% + 20mA
  • Line Voltage Regulation: 0.01% + 3mV
  • Load Voltage Regulation: 0.01% + 3mV
  • Line Current Regulation: 0.1% + 3mA
  • Load Current Regulation: 0.1% + 20mA
  • Voltage Supply: 110 ~ 220VAC
  • Product Status: Active product from SRA Soldering Products.
