BAT54AW Real Image BAT54AW Real Image1 BAT54AW Real Image2
Same model may have multiple batches, images only for reference.
BAT54AW Real Image BAT54AW Real Image1 BAT54AW Real Image2
BAT54AW Real Image BAT54AW Real Image1 BAT54AW Real Image2
Same model may have multiple batches, images only for reference.

BAT54AW

Part No BAT54AW
Manufacturer SMC Diode Solutions
Catalog Diodes, Rectifiers - Arrays
Description DIODE SCHOTTKY 30V 100MA SOT323
Datasheet
BAT54AW Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Diode Arrays
Mfr SMC Diode Solutions
Package Tape & Reel
Product Status Active
Diode Configuration 1 Pair Common Anode
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 30 V
Current - Average Rectified (Io) (per Diode) 100mA
Voltage - Forward (Vf) (Max) @ If 1 V @ 100 mA
Speed Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr) 5 ns
Current - Reverse Leakage @ Vr 2 µA @ 25 V
Operating Temperature - Junction 125°C (Max)
Mounting Type Surface Mount
Package / Case SC-70, SOT-323
Supplier Device Package SOT-323
Base Product Number BAT54
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.10.0070
Win Source Part Number 568856-BAT54AW
Ultra Librarian 3D Model Ultra Librarian BAT54AW CAD Model

Description

The 568856-BAT54AW is a diode array featuring two common anode Schottky diodes.

  • Application: Small Signal
  • Maximum DC Reverse Voltage: 30V
  • Forward Voltage: 1V @ 100mA
  • Reverse Recovery Time: 5ns
  • Current Leakage: 2µA @ 25V
  • Average Rectified Current per Diode: 100mA
  • Mounting: Surface Mount Device
  • Package: SC-70, SOT-323
  • Technology Series: Schottky
  • Supplier: SMC Diode Solutions
  • Status: Active
  • Suitable for: Various electronic circuits requiring diode arrays
