Same model may have multiple batches, images only for reference.
DS1-175-0002 Schurter Inc. – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

DS1-175-0002

Part No DS1-175-0002
Manufacturer Schurter Inc.
Catalog Common Mode Chokes
Description CMC 630MA 2LN TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Number of Lines 2
Current Rating (Max) 630mA
DC Resistance (DCR) (Max) 500mOhm
Voltage Rating - DC 600V
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Through Hole
Size / Dimension 0.689" L x 0.630" W (17.50mm x 16.00mm)
Case / Package Radial
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1531972-DS1-175-0002
Ultra Librarian 3D Model Ultra Librarian DS1-175-0002 CAD Model

Description
