XB4BW33G5 Schneider Electric – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

XB4BW33G5

Part No XB4BW33G5
Manufacturer Schneider Electric
Catalog Pushbutton Switches
Description HARMONY, 22MM ILLUMINATED PUSH B
Datasheet
XB4BW33G5 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Mounting Type Panel Mount, Front
Type Standard, Illuminated
Circuit DPST-NO/NC
Switch Function On-Off, Off-On
Current Rating (Amps) 6A (AC), 550mA (DC)
Voltage Rating - AC 120 V
Voltage Rating - DC 125 V
Actuator Type Round, Button, Flush
Color - Actuator/Cap Green
Illumination Type, Color LED, Green
Illumination Voltage (Nominal) 110 ~ 220 VAC
Termination Style Screw Terminal
Ingress Protection IP66/IP67/IP69/IP69K - Dust Tight, Water Resistant, Waterproof
Panel Cutout Dimensions Circular - 22.00mm Dia
Temperature Range - Operating -40°C ~ 70°C
Package Box
Supply and Demand Status Shortage
Win Source Part Number 1554637-XB4BW33G5
Ultra Librarian 3D Model Ultra Librarian XB4BW33G5 CAD Model
