The Samtec Inc. SFC-125-T2-L-D-A is part of the Tiger Eye™ SFC Series and is a Rectangular Connector with Headers, Receptacles, Female Sockets.

• Number of Positions: 50
• Features: Board Guide
• Connector Type: Receptacle
• Contact Type: Female Socket
• Positions Loaded: All
• Rows: 2
• Termination: Solder
• Fastening Type: Push-Pull
• Package: Tube
• Contact Material: Phosphor Bronze
• Voltage Rating: 350VAC
• Features: Mated Stacking Heights and Ingress Protection
• Applications: Not specified
• Standard Package: 16
• Mounting: SMD (SMT)
• Insulation Material: Liquid Crystal Polymer (LCP)
• Style: Board to Board or Cable
• Pitch - Mating: 0.050" (1.27mm)
• Contact Finish - Mating: Gold
• Contact Finish Thickness - Mating: 10.0µin (0.25µm)
• Contact Finish - Post: Tin
• Insulation Color: Black
• Row Spacing - Mating: 0.050" (1.27mm)
• Contact Length - Post: Not specified
• Insulation Height: 0.180" (4.57mm)
• Contact Shape: Square
• Temperature Range - Operating: -55°C ~ 125°C
• Current Rating (Amps): 3.1A per Contact
