RB161VA-20TR Rohm Semiconductor RB161VA-20TR real image RB161VA-20TR label picture
Same model may have multiple batches, images only for reference.
RB161VA-20TR Rohm Semiconductor RB161VA-20TR real image RB161VA-20TR label picture
RB161VA-20TR Rohm Semiconductor RB161VA-20TR real image RB161VA-20TR label picture
Same model may have multiple batches, images only for reference.

RB161VA-20TR

Part No RB161VA-20TR
Manufacturer Rohm Semiconductor
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 20V 1A TUMD2 / Diode Schottky 30V 1A 2-Pin TUMD T/R
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Rohm Semiconductor
Packaging Reel - TR
Status Not For New Designs
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 20V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 420mV @ 1A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 1mA @ 20V
Mounting SMD (SMT)
Case / Package TUMD2
Operating Temperature - Junction 125°C (Max)
Win Source Part Number 027118-RB161VA-20TR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name RB161VA-20
Introduction Date January 06, 2005
ECCN EAR99
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian RB161VA-20TR CAD Model

Description

The Rohm Semiconductor RB161VA-20TR is a Schottky diode with a voltage rating of 20V and a current rating of 1A.

  • Voltage Rating: 20V
  • Current Rating: 1A
  • Forward Voltage: 420mV @ 1A
  • Reverse Leakage Current: 1mA @ 20V
  • Operating Temperature: Up to 125°C
  • Package: TUMD2
  • Category: Discrete Semiconductor Products
  • Recommendation: Not recommended for new designs
  • Type: Fast recovery diode
  • Popularity: High popularity in the market
  • Supply and Demand Status: Sufficient
