Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Rohm Semiconductor
Packaging Reel - TR
Status Not For New Designs
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 80V
Current - Average Rectified (Io) 100mA
Voltage - Forward (Vf) (Max) @ If 1.2V @ 100mA
Reverse Recovery Time (trr) 4ns
Current - Reverse Leakage @ Vr 100nA @ 80V
Capacitance @ Vr, F 3pF @ 0.5V, 1MHz
Mounting SMD (SMT)
Case / Package UMD2
Operating Temperature - Junction 150°C (Max)
Win Source Part Number 005464-1SS355TE-17
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name 1SS355
Introduction Date April 16, 2000
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2019
Ultra Librarian 3D Model Ultra Librarian 1SS355TE-17 CAD Model

Description

Overview of 1SS355TE-17

The 1SS355TE-17 diode is crafted for high-frequency switching with exceptional reliability. This component is optimized for minimal signal distortion, providing an edge in various fast-evolving electronic applications.

Applications

  • High-speed communication equipment
  • Microprocessor systems
  • Ultra-low voltage applications
  • General-purpose switching

Features and Benefits

  • Optimal frequency response: Ensures minimal signal loss for high-speed applications.
  • Enhanced durability: Designed to withstand long-term use in demanding environments.
  • Versatile use: Suitable for a broad range of applications due to its universal design.

Additional Details

In addition to high-frequency performance, the 1SS355TE-17 represents reliability and precision in energy-sensitive environments. Its robust construction caters to advanced electronic systems where minimal signal interference is a prerequisite for operation.
