Products specifications Report Issue?

Categories Development Boards, Kits, Programmers
Manufacturer Texas Instruments
Main Purpose Power Management, ORing Controller / Load Share
Embedded No
Utilized IC / Part TPS2411
Primary Attributes N+1 Power Supplies
Secondary Attributes 3V ~ 16.5V Supply
Supplied Contents Board(s)
Win Source Part Number 797891-TPS2411EVM
Popularity Medium
Supply and Demand Status Limited
Family Name TPS2411
Introduction Date October 06, 2006
ECCN EAR99
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian TPS2411EVM CAD Model

Description

Introducing the TPS2411EVM from Texas Instruments

The TPS2411EVM is an evaluation module designed to demonstrate the robust performance and versatility of the TPS2411 hot-swap controller IC from Texas Instruments. This powerful little board is the perfect tool for engineers and developers who need to test the functionality and integration of the TPS2411 in their power management solutions.

Key Features of the TPS2411EVM

  • Hot-Swap Controller: At the heart of the TPS2411EVM is the TPS2411 IC, a hot-swap controller that allows users to safely insert and remove circuit boards from live backplanes without causing any electrical disruption.
  • Adjustable Current Limit: The evaluation module provides an adjustable current limit feature, enabling users to tailor the current threshold to meet the specific needs of their applications.
  • Under-Voltage and Over-Voltage Protection: The TPS2411EVM ensures your designs are safeguarded against voltage anomalies with built-in under-voltage and over-voltage lockout circuits.
  • Circuit Flexibility: The module is designed with flexibility in mind, allowing for easy configuration to match a wide range of power supply designs and applications.
  • Diagnostic Features: Equipped with diagnostic functionalities, the EVM can provide valuable feedback on the status of the power system through its fault and power good signals.

Applications

The TPS2411EVM is ideal for testing in various applications, including but not limited to:

  • Server and Telecom Hot-Swap Systems
  • Redundant Power Supplies
  • Industrial Systems
  • Network Equipment

Easy to Use and Integrate

Designed with the user in mind, the TPS2411EVM is easy to set up and integrate into existing systems. Its user-friendly interface allows for quick adjustments and modifications, making it an invaluable tool for rapid prototyping and testing. Whether you're designing a new power management system or looking to improve an existing one, the TPS2411EVM provides a convenient platform for exploring the capabilities of the TPS2411 hot-swap controller.

With the TPS2411EVM, Texas Instruments continues its tradition of providing innovative, high-quality tools for the electronics industry, ensuring that your power management solutions are both efficient and reliable.
