SGA-5589Z RF Micro Devices SGA-5589Z Real Image
Same model may have multiple batches, images only for reference.
SGA-5589Z RF Micro Devices SGA-5589Z Real Image
SGA-5589Z RF Micro Devices SGA-5589Z Real Image
Same model may have multiple batches, images only for reference.

SGA-5589Z

Part No SGA-5589Z
Manufacturer RF Micro Devices
Catalog RF Amplifiers
Description IC AMP HBT SIGE 4000MHZ SOT-89
Datasheet
SGA-5589Z Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer RF Micro Devices
Packaging Reel - TR
Status Obsolete(EOL)
Frequency 0Hz to 4GHz
P1dB 16.2dBm (41.7mW)
Gain 20.8dB
Noise Figure 3.4dB
RF Type Cellular, GSM, PCS, UMTS
Supply Voltage - Operating 3.5 V to 4.2 V
Operating Supply Current 54mA to 66mA
Test Frequency 1.95GHz
Case / Package SOT-89-3
Win Source Part Number 107379-SGA-5589Z
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SGA-5589Z CAD Model

Description

The RF Micro Devices SGA-5589Z is a high-performance RF amplifier designed for use in cellular, GSM, PCS, and UMTS applications.

  • Frequency Range: 0Hz to 4GHz
  • Gain: 20.8dB
  • Noise Figure: 3.4dB
  • P1dB: 16.2dBm (41.7mW)
  • Package: SOT-89-3
  • Supply Voltage: 3.5 V to 4.2 V
  • Operating Supply Current: 54mA to 66mA
  • Status: obsolete (EOL)
