R570463100 Real Image
Same model may have multiple batches, images only for reference.

R570463100

Part No R570463100
Manufacturer Radiall USA, Inc.
Catalog RF Switches
Description SP2 R S18 LSI 28 TL D P / RF Switch IC General Purpose SPDT 50Ohm Module
Datasheet
R570463100 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category RF/IF and RFID>RF Switches
Mfr Radiall USA, Inc.
Package Bulk
RF Type General Purpose
Circuit SPDT
Frequency Range 0Hz ~ 18GHz
Isolation 60dB (min)
Insertion Loss 0.35dB (max)
Test Frequency 18GHz
Impedance 50Ohm
Voltage - Supply 24V ~ 30V
Temperature Range - Operating -40°C ~ 85°C
Package / Case Module, SMA Connectors
Supplier Device Package Module
RoHS Status Not applicable
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8543.70.9860
Other Names R570.463.100,2201-R570463100
Standard Package 1
Win Source Part Number 1224938-R570463100
Ultra Librarian 3D Model Ultra Librarian R570463100 CAD Model

Description

The R570463100 is an RF switch manufactured by Radiall USA, Inc.

  • Manufacturer: Radiall USA, Inc.
  • Type: RF Switch
  • Module: Yes
  • Connectors: SMA
  • Circuit Topology: SPDT
  • Frequency Range: 0Hz to 18GHz
  • Test Frequency: 18GHz
  • Insertion Loss: 0.35dB (max)
  • Isolation: 60dB (min)
  • Voltage Supply: 24V to 30V
  • Operating Temperature: -40°C to 85°C
  • Category: RF/IF and RFID
  • Application: General-Purpose RF Switch
