The TX1279 is a high-performance common mode choke designed for signal integrity and noise reduction in diverse electronic applications. This choke, manufactured by Pulse, effectively attenuates common-mode noise while allowing differential signals to pass through with minimal impedance. The surface mount configuration enables efficient automated assembly processes. It's built for robustness and performance in demanding environments.

Applications

• USB interfaces
• IEEE 1394 (FireWire) interfaces
• High-speed data lines
• CAN bus systems
• Ethernet ports

Features

• Surface mount design for automated assembly
• High common mode impedance for noise suppression
• Low differential mode impedance to maintain signal integrity
• Compact footprint
• RoHS compliant

Benefits

• Improved signal integrity in high-speed data transmission
• Reduced EMI (Electromagnetic Interference) emissions
• Enhanced system reliability by mitigating noise-related issues
• Facilitated compliance with regulatory standards
• Simplified PCB layout and reduced component count

Additional Details

The TX1279 features a compact design suitable for dense PCB layouts. Its high common mode impedance effectively blocks unwanted noise, while its low differential mode impedance ensures minimal signal attenuation. This choke is suitable for applications requiring high-speed data transmission and robust noise immunity. Consult the manufacturer's datasheet for detailed electrical specifications including impedance characteristics, DC resistance, rated current, and isolation voltage. The rugged construction of the TX1279 ensures reliable performance in a variety of operating conditions.
