Products specifications

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 40V
Current - Average Rectified (Io) 500mA
Voltage - Forward (Vf) (Max) @ If 510mV @ 500mA
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 20μA @ 40V
Mounting SMD (SMT)
Case / Package SOD-123
Operating Temperature - Junction -55°C to 150°C
Win Source Part Number 1083539-NRVB0540T1G
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian NRVB0540T1G CAD Model

Description

ON Semiconductor NRVB0540T1G - High-Efficiency Schottky Barrier Rectifier

The ON Semiconductor NRVB0540T1G is a state-of-the-art Schottky Barrier Rectifier designed for high-efficiency power management applications. This robust rectifier is engineered to provide low forward voltage drop while maintaining superior thermal performance, making it an ideal choice for a wide range of electronic devices.

Key Features

  • Low Forward Voltage: The device features a low forward voltage drop, which enhances system efficiency by minimizing power loss during operation.
  • High Current Capability: With a forward continuous current rating of 5A, the NRVB0540T1G can handle high current applications with ease.
  • High Surge Capability: It is designed to withstand surge currents, ensuring reliability and stability in demanding situations.
  • Low Power Loss: High efficiency is achieved through low power loss, which is essential for energy-sensitive designs.
  • Lead-Free and RoHS Compliant: The product is environmentally friendly, adhering to the latest RoHS directives for the reduction of hazardous substances.

Applications

The NRVB0540T1G is versatile and can be used in a variety of applications, including:

  • Switch-mode power supplies (SMPS)
  • DC-DC converters
  • Free-wheeling diodes in converters and motor control circuits
  • Power management systems
  • Automotive applications
  • LED lighting

Product Specifications

The NRVB0540T1G operates at a peak repetitive reverse voltage (VRRM) of 40V, which allows it to be used in systems with moderate voltage requirements. Its power dissipation is managed efficiently due to the device's low thermal resistance. The package is SMB (Surface-Mounted Device) which is suitable for automated PCB assembly processes and space-constrained applications.

ON Semiconductor's commitment to quality and performance is evident in the NRVB0540T1G Schottky Barrier Rectifier. It is designed to meet the needs of modern, high-performance power management systems, providing designers with a reliable and efficient rectifying solution. With its combination of low forward voltage, high current capability, and robust surge protection, the NRVB0540T1G is a prime choice for engineers looking to enhance the efficiency and longevity of their electronic products.
