Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - FETs, MOSFETs - FET, MOSFET Arrays
Mfr ON Semiconductor
Series *
Package Bulk
Product Status Active
Base Product Number MCH3307
Standard Package 2,664 pcs
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 225285-MCH3307-TL-E
Ultra Librarian 3D Model Ultra Librarian MCH3307-TL-E CAD Model

Description

ON Semiconductor MCH3307-TL-E MOSFET Overview

The MCH3307-TL-E from ON Semiconductor is a high-performance P-Channel MOSFET designed to deliver efficient power management and switching capabilities for a wide range of applications. This device is notable for its low on-resistance and high-speed switching, making it an ideal choice for power conversion and management tasks in both commercial and industrial settings.

Key Features

  • Device Type: P-Channel MOSFET
  • Configuration: Single
  • Drain-Source Voltage (V<sub>DS): -30V
  • Continuous Drain Current (I<sub>D): -6A
  • Power Dissipation (P<sub>D): 1.25W
  • Gate-Source Voltage (V<sub>GS): ±20V
  • On-Resistance (R<sub>DS(on)): 45 mΩ
  • Operating Temperature Range: -55°C to +150°C
  • Mounting Type: Surface Mount
  • Package / Case: SOT-23-6 Thin, SuperSOT™-6, TSOT-23-6

Applications

The MCH3307-TL-E MOSFET is suitable for a variety of applications that require efficient power control, including:

  • Power Management Systems
  • DC/DC Converters
  • Load Switches
  • Battery Management
  • Motor Control Circuits
  • Portable Devices

Product Advantages

ON Semiconductor's MCH3307-TL-E provides several advantages that make it a reliable and efficient choice for designers and engineers:

  • Efficiency: Low on-resistance reduces conduction losses, enhancing overall efficiency.
  • Thermal Management: Good thermal characteristics ensure reliability even under high temperature operation.
  • Size: The compact SOT-23-6 package is ideal for space-constrained applications.
  • Robustness: The device can handle continuous drain currents up to -6A, making it robust for various applications.

Overall, the MCH3307-TL-E by ON Semiconductor is a versatile and robust component that offers high performance in power management and switching applications, backed by the quality and reliability that ON Semiconductor is known for.
