Category Discrete Semiconductor Products - Transistors - FETs, MOSFETs - FET, MOSFET Arrays
Mfr onsemi
Series Automotive, AEC-Q101
Package Tape & Reel
Technology MOSFET (Metal Oxide)
Configuration 2 N-Channel (Dual)
Drain to Source Voltage (Vdss) 40V
Current - Continuous Drain (Id) @ 25°C 25A (Ta) , 145A (Tc)
Rds On (Max) @ Id, Vgs 2.65mOhm @ 20A, 10V
Vgs(th) (Max) @ Id 2.2V @ 90µA
Gate Charge (Qg) (Max) @ Vgs 25nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds 3170pF @ 25V
Power - Max 3.5W (Ta)
Temperature Range - Operating -55°C ~ 175°C (TJ)
Mounting Type Surface Mount
Package / Case 8-PowerTDFN
Supplier Device Package 8-DFN (5x6) Dual Flag (SO8FL-Dual)
Base Product Number NVMFD5
Standard Package 1,500
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Win Source Part Number 1350136-NVMFD5C446NLWFT1G
Ultra Librarian 3D Model Ultra Librarian NVMFD5C446NLWFT1G CAD Model

Description

The NVMFD5C446NLWFT1G is a cutting-edge power MOSFET device from ON Semiconductor, renowned for its high efficiency and thermal performance. This product is designed to meet the rigorous demands of modern electronic applications, providing a reliable and robust solution for power management tasks.

Key Features

  • Low R<sub>DS(on): The device boasts an exceptionally low on-resistance, which minimizes conduction losses and improves overall efficiency, making it ideal for high-performance applications.
  • High Continuous Drain Current (I<sub>D): With its capability to handle a high continuous drain current, this MOSFET can support applications requiring significant power throughput without compromising performance.
  • Power-SO8 FLMP Package: The device comes in a Power-SO8 FLMP package that offers a compact footprint while ensuring excellent thermal dissipation. This packaging is suitable for space-constrained applications that also require efficient cooling.
  • Low Gate Charge (Q<sub>g): The low gate charge ensures fast switching performance, which is essential for applications like DC-DC converters, motor drives, and power supplies.

Applications

The NVMFD5C446NLWFT1G is versatile and can be used in a variety of applications, including:

  • Switching regulators
  • DC-DC converters
  • Power supply modules
  • Motor controls
  • Automotive systems
  • Computing and server systems

Technical Specifications

Parameter Value R<sub>DS(on) Typically 4.4 mΩ I<sub>D Up to 35 A Package Power-SO8 FLMP Gate Charge (Q<sub>g) Typically 13.7 nC

Overall, the NVMFD5C446NLWFT1G from ON Semiconductor is an excellent choice for designers looking for a power MOSFET that offers high efficiency, thermal performance, and reliability in a wide range of applications.
