Products specifications

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr ON Semiconductor
Package Tape & Reel
Product Status Obsolete
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 30 V
Current - Average Rectified (Io) 2A
Voltage - Forward (Vf) (Max) @ If 445 mV @ 2 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 1 mA @ 30 V
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Supplier Device Package SMB
Base Product Number MBRS130
Standard Package 2,500 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 830348-MBRS130LT3
Ultra Librarian 3D Model Ultra Librarian MBRS130LT3 CAD Model

Description

ON Semiconductor MBRS130LT3 Schottky Power Rectifier

The MBRS130LT3 is a robust Schottky power rectifier from the trusted manufacturer ON Semiconductor. This high-performance component is designed to offer efficient and reliable operation in a variety of applications, including power supply, DC-DC conversion, and as a polarity protection diode.

Key Features

  • Low Forward Voltage Drop: The MBRS130LT3 boasts a low forward voltage drop, which enhances system efficiency and reduces thermal issues, making it an excellent choice for applications where power efficiency is crucial.
  • High Surge Capacity: With its impressive surge capacity, this rectifier can handle high current peaks without compromising its integrity, ensuring a reliable performance even under stressful conditions.
  • Compact Design: The device comes in a small, surface-mount package (SMC), which allows for a more compact design in end products, saving valuable board space.
  • Guardring for Overvoltage Protection: The inclusion of a guardring provides enhanced protection against voltage spikes, increasing the longevity and reliability of the rectifier.
  • High Temperature Operation: Capable of operating at high temperatures, the MBRS130LT3 is suitable for demanding environments and applications that generate significant heat.

Applications

The MBRS130LT3 is versatile and can be used in a wide range of electronic circuits. Common applications include:

  • Switching power supplies
  • Converters
  • Free-wheeling diodes
  • Reverse battery protection
  • Automotive applications
  • Portable devices and power management systems

Technical Specifications

  • Package: SMC
  • Peak Repetitive Reverse Voltage: 30 V
  • Average Rectified Forward Current: 1 A
  • Non-Repetitive Peak Forward Surge Current: 40 A
  • Operating Junction Temperature: -65°C to +150°C

In summary, the MBRS130LT3 from ON Semiconductor is a high-quality Schottky power rectifier that offers a combination of low power loss, high efficiency, and space-saving packaging, making it a go-to choice for designers looking to enhance their power management systems.
