Products specifications

Categories Discrete Semiconductor Products
Features Diode Schottky 10 V 2A Surface Mount SMA
Manufacturer ON Semiconductor
Package Reel - TR
Part Status Obsolete
Speed Fast Recovery =< 500ns, > 200mA (Io)
Mounting Surface Mount
Package DO-214AC, SMA
Case / Package SMA
Family Name MBRA210
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Other Part Number MBRA210LT3OSCT, MBRA210LT3OSTR, MBRA210LT3OSDKR
Quantity per package 5000
Popularity High
Supply and Demand Status Balance
Win Source Part Number 925995-MBRA210LT3
Ultra Librarian 3D Model Ultra Librarian MBRA210LT3 CAD Model

Description

The MBRA210LT3 from ON Semiconductor is a highly efficient, surface mount Schottky Barrier Rectifier designed for applications requiring low voltage, high-frequency rectification, or as free-wheeling and polarity protection diodes. This robust rectifier is a popular choice in the electronics industry due to its compact size, superior reliability, and energy-saving capabilities.

Key Features

  • Low Forward Voltage Drop: The MBRA210LT3 boasts a low forward voltage drop, which enhances system efficiency by reducing power losses during the conduction phase.
  • High Current Capability: With a high forward surge current rating, this device can handle high current spikes, making it suitable for demanding applications.
  • Power Dissipation: It has a power dissipation rating that ensures reliable operation even under high power and temperature conditions.
  • Guard Ring Die Construction: The inclusion of a guard ring die construction provides enhanced reliability through transient protection, which is crucial for voltage-sensitive applications.
  • Package: The MBRA210LT3 comes in a compact SMB package, which is ideal for space-constrained applications and helps in achieving a high packing density on PCBs.

Applications

The versatility of the MBRA210LT3 allows it to be used in a wide array of applications, including:

  • Power supply management
  • DC-DC converters
  • Automotive applications
  • Free-wheeling diodes in converters and motor control circuits
  • Reverse battery protection
  • Portable devices and battery charging circuits

Technical Specifications

Some of the essential technical specifications of the MBRA210LT3 include:

  • Peak Repetitive Reverse Voltage: 100 V
  • Average Rectified Forward Current: 2 A
  • Non-Repetitive Peak Forward Surge Current: 50 A
  • Operating Junction Temperature Range: -55°C to +150°C
  • Storage Temperature Range: -65°C to +150°C

ON Semiconductor's commitment to quality ensures that the MBRA210LT3 Schottky Barrier Rectifier is a reliable and cost-effective solution for high-efficiency power rectification needs.
