Products specifications

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Tape and Reel
Status Obsolete
Diode Type Schottky
Voltage - DC Reverse (Vr) (Maximum) 30V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Maximum) at If 550mV at 1A
Speed Fast Recovery = 200mA (Io)
Current - Reverse Leakage at Vr 1mA at 30V
Mounting Style SMD
Manufacturer Package DO-214AC, SMA
Supplier Device Package SMA (DO-214AC)
Operating Temperature - Junction -65°C ~ 125°C
Manufacturer Pack Quantity 5,000
MSL Level 1 (Unlimited)
Win Source Part Number 1174767-FMKA130
Manufacturer Homepage www.fairchildsemi.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian FMKA130 CAD Model

Description

The FMKA130 from ON Semiconductor is a state-of-the-art Schottky barrier diode designed for high-efficiency power management applications. This diode is well-suited for a variety of electronic devices and systems, offering superior performance in a compact, surface-mount package.

Key Features:

  • Low Forward Voltage Drop: The FMKA130 boasts a low forward voltage drop, reducing power loss and improving efficiency during operation. This characteristic is particularly beneficial in applications where power conservation is critical.
  • High Current Capability: With its robust design, the FMKA130 can handle high current throughput, making it an ideal choice for power supply and converter circuits.
  • Fast Switching Speed: The diode's fast switching speed ensures minimal loss of efficiency during the transition between conducting and non-conducting states, which is essential for high-frequency applications.
  • Thermal Efficiency: The device's excellent thermal characteristics help in maintaining stability and performance even under high temperature operating conditions.
  • Guard Ring Die Construction: The guard ring design enhances ruggedness and long-term reliability, which is crucial for industrial and automotive applications where components are subjected to harsh conditions.

Applications:

The FMKA130 is versatile and can be used across a wide range of applications, including:

  • DC-DC Converters
  • Power Supply Units (PSUs)
  • Automotive Systems
  • Battery Charging Circuits
  • Reverse Battery Protection
  • Free-Wheeling Diodes in Converters and Motor Control Circuits

Package and Quality:

The FMKA130 comes in a compact SOD-123 package, which is not only space-saving but also compatible with automatic pick-and-place equipment, facilitating easy assembly in mass production. ON Semiconductor's commitment to quality ensures that each diode meets stringent standards, providing reliability and performance that engineers and designers can trust.
