Products specifications

Categories Integrated Circuits
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Motor Type - AC, DC Brushed DC
Purpose Driver - Fully Integrated, Control and Power Stage
Technology Bi-CMOS
Applications General Purpose
Output Current 1.4A
Supply Voltage - Operating 2.8 V to 5.5 V
Voltage - Load 1.5 V to 15 V
Temperature Range - Operating -30°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 16-SSOP
Win Source Part Number 1064521-LV8405V-TLM-E
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LV8405V-TLM-E CAD Model

Description

The LV8405V-TLM-E from ON Semiconductor is a versatile and efficient motor driver IC designed to cater to a wide range of applications requiring precise motor control. This compact and robust integrated circuit is ideal for driving small brushed DC motors, making it a perfect choice for portable devices, consumer electronics, and automotive applications.

Key Features:

  • Wide Operating Voltage Range: The LV8405V-TLM-E operates efficiently across a voltage range of 2.5V to 9.0V, allowing for flexible integration into various circuit designs and ensuring compatibility with a variety of power sources.
  • Low Voltage Operation: Its ability to operate at low voltages makes it particularly suitable for battery-powered applications where power efficiency is critical.
  • High Output Current: The device can deliver an output current of up to 1A, providing sufficient drive capability for small to medium-sized motors.
  • Low Saturation Voltage: The motor driver features a low saturation voltage, which minimizes power loss and improves overall efficiency during operation.
  • Thermal Shutdown Function: To ensure the protection of the IC and the motor, the LV8405V-TLM-E is equipped with a thermal shutdown function that prevents damage due to overheating.

Applications:

  • Portable electronic devices
  • Battery-powered toys
  • Small household appliances
  • Automotive applications

The LV8405V-TLM-E motor driver IC is presented in a compact package, making it suitable for space-constrained applications. Its simple control logic facilitates easy integration into existing designs, while its robustness and reliability make it a preferred choice for designers looking for a high-performance motor control solution. With ON Semiconductor's commitment to quality, the LV8405V-TLM-E represents a solid investment for your motor control needs.
