Products specifications

Category Integrated Circuits (ICs) - Power Management (PMIC) - Motor Drivers, Controllers
Mfr ON Semiconductor
Package Tape & Reel
Product Status Obsolete
Motor Type - AC, DC Brushed DC
Function Controller - Commutation, Direction Management
Output Configuration Pre-Driver - Half Bridge (2)
Interface PWM
Applications Fan Controller
Voltage - Supply 6V ~ 16V
Temperature Range - Operating -40°C ~ 90°C (TA)
Mounting Type Surface Mount
Package / Case 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
Supplier Device Package 10-Micro
Base Product Number LB11851
Standard Package 4,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 922707-LB11851FA-BH
Ultra Librarian 3D Model Ultra Librarian LB11851FA-BH CAD Model

Description

The LB11851FA-BH from ON Semiconductor is a versatile and efficient motor driver IC designed to cater to a wide range of applications requiring precise motor control. This high-quality integrated circuit is an excellent choice for designers looking to implement a reliable motor driver solution in their projects.

Key Features

  • Output Current: The LB11851FA-BH offers a substantial output current, making it suitable for driving small to medium-sized motors.
  • Operating Voltage Range: It operates over a wide range of voltages, which ensures compatibility with various power supply standards and allows for flexible design options.
  • Low Power Consumption: Designed with energy efficiency in mind, this motor driver IC consumes low power, thereby reducing the overall power requirements of the system.
  • Protection Features: The device includes several built-in protection features such as thermal shutdown, under-voltage lockout, and overcurrent protection, ensuring safe operation under various conditions.

Applications

The LB11851FA-BH is engineered to drive brushless DC motors and is ideal for applications in:

  • Consumer Electronics
  • Office Automation Equipment
  • Home Appliances
  • Small Industrial Equipment

Product Advantages

ON Semiconductor's LB11851FA-BH stands out in the market due to its integration of control and drive functions, which simplifies the circuit design and reduces the number of external components required. This results in a more compact system design and can contribute to cost savings in mass production. Additionally, its robust protection features ensure long-term reliability and performance, which is crucial in extending the lifespan of the end product.

Technical Specifications

  • Package: The IC comes in a compact package, which is suitable for space-constrained applications.
  • Quality and Reliability: ON Semiconductor is known for its commitment to quality, and the LB11851FA-BH is manufactured to meet high standards of reliability and performance.

Overall, the LB11851FA-BH motor driver IC by ON Semiconductor is an exceptional choice for designers and engineers looking for a high-performance, reliable, and cost-effective solution for motor control applications.
