Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Motor Type - Stepper Bipolar
Motor Type - AC, DC Brushed DC
Purpose Driver - Fully Integrated, Control and Power Stage
Technology Power MOSFET
Applications Battery Powered
Output Current 1.8A
Supply Voltage - Operating 1.8 V to 7 V
Voltage - Load 0 V to 11 V
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 12-WSON (3x2)
Win Source Part Number 106258-DRV8839DSSR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name DRV8839DSSR
Introduction Date February 22, 2013
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian DRV8839DSSR CAD Model

Description

DRV8839DSSR DC Motor Driver Circuit

Ideal for portable electronic devices, the DRV8839DSSR is a dual H-bridge driver that facilitates the control of small DC motors and bipolar stepper motors. Featuring high-grade protection features and a simple interface, this motor driver supports precise motion control, making it suitable for industrial applications as well.

  • Industrial automation
  • Printers
  • ATM machines

Features and Benefits

  • Supply voltage range from 1.8V to 7V
  • Efficient low-power consumption
  • Small QFN package for high-density mounting

The DRV8839DSSR offers diagnostic features such as open-load detection and short-circuit protection, providing robust solutions for various mechanical systems.
