EE-SM3B Omron
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Sensors, Transducers - Optical Sensors - Photointerrupters - Slot Type - Transistor Output
Mfr Omron
Package Bulk
Product Status Obsolete
Sensing Distance 0.118" (3mm)
Sensing Method Through-Beam
Output Configuration Photodarlington
Current - DC Forward (If) (Max) 15 mA
Current - Collector (Ic) (Max) 20 mA
Voltage - Collector Emitter Breakdown (Max) 24 V
Response Time 180µs, 60µs
Temperature Range - Operating -20°C ~ 60°C
Mounting Type Through Hole
Package / Case PCB Mount
Type Unamplified
Standard Package 100 pcs
Moisture Sensitivity Level (MSL) Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.49.8000
Win Source Part Number 588270-EE-SM3B
Ultra Librarian 3D Model Ultra Librarian EE-SM3B CAD Model

Description

The 588270-EE-SM3B is an optical sensor from Omron.

  • Type: slot-type photointerrupter with a transistor output
  • Applications: precise sensing and detection
  • Sensing Distance: 0.118 inches (3mm)
  • Voltage Supply: up to 24V
  • Maximum Collector Current: 20mA
  • Output Configuration: photodarlington
  • Response Time: 180μs or 60μs
  • Mounting: through-hole
  • Package: bulk
  • Operating Temperature: -20°C to 60°C
  • Status: obsolete
