Product Overview: 74LVC1G175GW Single D-type Flip-flop by NXP

The 74LVC1G175GW is a high-performance, single D-type flip-flop with asynchronous clear functionality, designed and manufactured by NXP Semiconductors. This compact and efficient integrated circuit is part of the LVC family, which is known for its low-voltage operation and high-speed interface technology. The 74LVC1G175GW is housed in a leadless TSSOP5 (SOT353) package, making it suitable for space-constrained applications.

Key Features

• Low Voltage Operation: The device operates at a voltage range of 1.65V to 5.5V, which allows for compatibility with various logic levels and the ability to interface with both 3.3V and 5V systems.
• High-Speed Performance: With a typical propagation delay of only 3.7ns at 3.3V, this flip-flop provides fast data transfer, making it ideal for high-speed data processing applications.
• Power Efficiency: The 74LVC1G175GW is designed for low power consumption, featuring a low static and dynamic power consumption, which is essential for battery-powered and power-sensitive designs.
• Asynchronous Clear: The inclusion of an asynchronous clear input allows for the immediate reset of the flip-flop, which is crucial for initializing circuits and error recovery processes.
• 5-Bit Configuration: The device's TSSOP5 packaging includes five pins, which are the data input (D), clock input (CP), asynchronous clear input (nCLR), output (Q), and ground (GND), providing a straightforward interface for designers.

Applications

The 74LVC1G175GW's versatile features make it suitable for a wide range of applications, including:

• Data storage and transfer
• Signal processing
• Control systems
• Communication systems
• Portable and battery-powered devices
• Computing and logic interfaces

Quality and Reliability

NXP's commitment to quality ensures that the 74LVC1G175GW meets stringent industry standards. The device is fabricated with advanced silicon gate CMOS technology, providing robustness and reliability. It also features ESD protection, ensuring resilience against electrostatic discharge events during handling and operation.

For designers looking for a reliable and high-performance single D-type flip-flop, the 74LVC1G175GW from NXP offers an excellent balance of speed, power efficiency, and compact form factor, making it an ideal choice for a variety of digital applications.
