NJM3717E2-TE2

Part No NJM3717E2-TE2
Manufacturer Nisshinbo Micro Devices Inc.
Catalog PMIC - Motor Drivers, Controllers
Description IC STEPPER MOTOR DRIVER 20EMP
Datasheet
NJM3717E2-TE2 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - Motor Drivers, Controllers
Mfr Nisshinbo Micro Devices Inc.
Package Tape & Reel
Product Status Obsolete
Motor Type - Stepper Bipolar
Function Driver - Fully Integrated, Control and Power Stage
Output Configuration Half Bridge (2)
Interface Parallel
Technology Bipolar
Step Resolution 1, 1/2
Applications General Purpose
Current - Output 1A
Voltage - Supply 4.75V ~ 5.25V
Voltage - Load 10V ~ 45V
Temperature Range - Operating -40°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case 20-SOIC (0.209", 5.30mm Width)
Supplier Device Package 20-SOP
Base Product Number NJM3717
Standard Package 1,500 pcs
ECCN OBSOLETE
Win Source Part Number 255451-NJM3717E2-TE2
Ultra Librarian 3D Model Ultra Librarian NJM3717E2-TE2 CAD Model

Description

The NJM3717E2-TE2 is a motor driver and controller integrated circuit designed for general-purpose applications.

  • Current Output: 1A
  • Output Configuration: half bridge
  • Voltage Load: ranges from 10V to 45V
  • Supports: bipolar stepper motors
  • Voltage Supply: between 4.75V and 5.25V
  • Package: tape and reel, with a standard package of 1,500 pcs
  • Manufactured by: Nisshinbo Micro Devices Inc.
