TB6569FG,8,EL Toshiba Semiconductor and Storage TB6569FG,8,EL Real Image
Same model may have multiple batches, images only for reference.
TB6569FG,8,EL Toshiba Semiconductor and Storage TB6569FG,8,EL Real Image
TB6569FG,8,EL Toshiba Semiconductor and Storage TB6569FG,8,EL Real Image
Same model may have multiple batches, images only for reference.

TB6569FG,8,EL

Part No TB6569FG,8,EL
Manufacturer Toshiba Semiconductor and Storage
Catalog PMIC - Motor Drivers, Controllers
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs)>PMIC - Motor Drivers, Controllers
Mfr Toshiba Semiconductor and Storage
Package Tape & Reel
Motor Type - AC, DC Brushed DC
Function Driver - Fully Integrated, Control and Power Stage
Output Configuration Half Bridge (2)
Interface Parallel, PWM
Technology Bi-CMOS
Applications General Purpose
Current - Output 1.5A
Voltage - Supply 10V ~ 45V
Voltage - Load 10V ~ 45V
Temperature Range - Operating -40°C ~ 85°C (TA)
Mounting SMD (SMT)
Package / Case 16-BSOP (0.252", 6.40mm Width) + 2 Heat Tabs
Supplier Device Package 16-HSOP
Base Product Number TB6569
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1314417-TB6569FG,8,EL
Ultra Librarian 3D Model Ultra Librarian TB6569FG,8,EL CAD Model

Description

The TB6569FG,8,EL is an integrated circuit (IC) manufactured by Toshiba Semiconductor and Storage.

  • Function: Fully Integrated Driver with Control and Power Stage Functions
  • Output Configuration: Half Bridge
  • Maximum Current Output: 1.5A
  • Motor Type: Brushed DC Motors
  • Voltage Load: 10V to 45V
  • Package: 16-BSOP with 2 Heat Tabs
  • Interface: Parallel and PWM
  • Temperature Range: -40°C to 85°C (TA)
