WP4P+ Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category RF and Wireless - RF Power Dividers/Splitters
Mfr Mini-Circuits
Series -
Package Tape & Reel
Product Status Active
Insertion Loss 0.7dB
Frequency 1.71 GHz ~ 2.025 GHz
Specifications Isolation (Min) 19dB, 4° Imbalance (Max)
Size / Dimension 0.118" L x 0.118" W x 0.039" H (3.00mm x 3.00mm x 0.99mm)
Package / Case 12-VQFN Exposed Pad
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8548.00.0000
Win Source Part Number 1380281-WP4P+
Ultra Librarian 3D Model Ultra Librarian WP4P+ CAD Model

Description

The Mini-Circuits 1380281-WP4P+ is an RF power divider/splitter designed for use in RF and wireless applications.

  • Series: Mini-Circuits
  • Product Status: Active
  • Frequency: 1.71 GHz ~ 2.025 GHz
  • Size / Dimension: 0.118" L x 0.118" W x 0.039" H (3.00mm x 3.00mm x 0.99mm)
  • Insertion Loss: 0.7dB
  • Isolation: 19dB
  • Imbalance: 4° Max
  • Description: A reliable and high-quality RF power divider/splitter that meets the demands of RF and wireless systems.
