Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tray
Status Active
Type Fanout Buffer (Distribution), Multiplexer
Number of Circuits 1
Differential - Input and Output Yes/Yes
Input HSTL, LVECL, LVPECL
Output LVECL, LVPECL
Maximum Input Frequency 3GHz
Supply Voltage - Operating 2.375 V to 3.8 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 32-TQFP (7x7)
Win Source Part Number 031644-SY100EP111UTG
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian SY100EP111UTG CAD Model

Description

The SY100EP111UTG is a versatile clock distribution chip designed by Microchip Technology, renowned for its high-speed integrated circuits. This particular model is a 1:9 differential PECL/ECL clock driver, offering precise timing solutions for advanced electronic systems. It operates with a dual supply voltage of 3.3V or 5V, making it suitable for a wide range of applications.

Key Features:

  • High-Speed Performance: The SY100EP111UTG delivers exceptional speed, capable of handling clock frequencies up to 3GHz, which makes it ideal for high-performance computing and data communication systems.
  • Differential PECL/ECL Outputs: With nine differential outputs, this clock driver ensures low-skew and low-jitter signal distribution, critical for maintaining signal integrity in complex electronic systems.
  • Flexible Voltage Operation: It supports both 3.3V and 5V power supply operation, providing design flexibility and compatibility with various logic families.
  • Enhanced Signal Stability: The device features an internal input resistor and an on-chip termination to VBB that provides a Thevenin equivalent termination scheme for AC-coupled inputs, enhancing signal stability and reducing the need for external components.

Applications:

The SY100EP111UTG is suitable for a variety of high-speed applications, including but not limited to:

  • Telecommunication and networking equipment
  • High-speed servers and workstations
  • Data acquisition and signal processing systems
  • Automated test equipment

Product Specifications:

Parameter Value Package Type 16-Lead TSSOP Operating Temperature Range -40°C to +85°C Supply Voltage (VCC) 3.3V ± 10% or 5V ± 10% Frequency Range Up to 3GHz Output Type Differential PECL/ECL

Overall, the SY100EP111UTG from Microchip Technology is an exceptional choice for designers looking for a high-speed, reliable, and flexible clock distribution solution.
