Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Active
Number of I/O 16
Interrupt Output Yes
Features POR
Output Type Push-Pull
Current - Output Source/Sink 25mA
Max Frequency 400kHz
Supply Voltage - Operating 2 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 28-QFN (6x6)
Win Source Part Number 044632-MCP23016-I/ML
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name MCP23016
Introduction Date November 25, 2002
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian MCP23016-I/ML CAD Model

Description

Microchip Technology's MCP23016-I/ML

The MCP23016-I/ML is a versatile integrated circuit designed and produced by Microchip Technology, a leading provider of smart, connected, and secure embedded control solutions. This particular device is a member of Microchip's expansive family of I/O expanders, which are engineered to provide additional I/O ports for a host controller, typically a microcontroller or microprocessor. The MCP23016-I/ML offers a convenient and efficient way to expand the I/O capabilities of your embedded system without the need to increase the size or complexity of your main controller.

At the heart of the MCP23016-I/ML is a 16-bit I/O expander with an I²C interface. This allows for easy communication with the host controller using a simple two-wire serial interface, which is widely supported by many microcontrollers. The I²C interface operates at a standard 100kHz, which is suitable for most low-speed I/O expansion requirements. The device comes in a compact 28-pin QFN (Quad Flat No-lead) package, denoted by the 'ML' suffix, which is ideal for space-constrained applications.

The MCP23016-I/ML features two 8-bit ports (Port A and Port B) that can be independently controlled. Each port can be configured as an input or output, allowing for a flexible arrangement that suits a variety of application needs. Additionally, the device includes built-in interrupt output pins that can be configured to alert the host controller when input changes occur, further enhancing its utility in responsive control systems.

One of the standout attributes of the MCP23016-I/ML is its robust design, which includes high-noise immunity and low power consumption. The device is specified for operation over the industrial temperature range (-40°C to +85°C), making it suitable for harsh environments. Furthermore, this I/O expander is fully compatible with 5V I²C buses, making it a versatile choice for interfacing with both legacy and modern systems.

Whether you're designing a complex industrial control system, adding more inputs to a home automation project, or simply running out of I/O pins on your microcontroller, the MCP23016-I/ML from Microchip Technology is an excellent solution that combines performance, flexibility, and reliability in a compact form factor.
