Products specifications

Manufacturer Texas Instruments
Packaging Reel
Type Zener
Unidirectional Channels 4
Voltage - Reverse Standoff (Typ) 3.6V (Maximum)
Voltage - Breakdown (Min) 4.5V
Voltage - Clamping (Maximum) at Ipp 6.5V (Typ)
Current - Peak Pulse (10/1000μs) 25A (8/20μs)
Power - Peak Pulse 170W
Power Line Protection No
Applications Use For General
Capacitance at Frequency 4.5pF at 1MHz
Temperature Range - Operating -40°C ~ 125°C
Mounting Style SMD
Manufacturer Package SC-74A, SOT-753
Supplier Device Package SOT-23-5
Manufacturer Pack Quantity 3,000
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 809283-ESDS314DBVR
Ultra Librarian 3D Model Ultra Librarian ESDS314DBVR CAD Model

Description

Overview of Texas Instruments ESDS314DBVR

The Texas Instruments ESDS314DBVR is a highly integrated circuit designed to provide superior Electrostatic Discharge (ESD) protection for electronic devices. This robust component is specifically engineered to safeguard high-speed data lines and other sensitive circuits from the potentially damaging effects of ESD events. The ESDS314DBVR is an ideal choice for a wide range of applications, including consumer electronics, telecommunications, and industrial equipment.

Key Features

  • Low Capacitance: The ESDS314DBVR offers ultra-low capacitance, typically around 0.25 pF, which makes it suitable for protecting high-speed data lines without compromising signal integrity.
  • High ESD Protection: This device is capable of withstanding ESD strikes up to ±12 kV (contact discharge) and ±15 kV (air-gap discharge) as per the IEC 61000-4-2 international standard, ensuring robust protection for sensitive components.
  • Low Clamping Voltage: It features a low dynamic resistance and clamping voltage, which provides enhanced protection for downstream electronics by reducing the energy of ESD events.
  • Small Form Factor: The ESDS314DBVR comes in a small SOT-23 (DBV) package, making it an excellent choice for space-constrained applications.
  • Wide Operating Range: It operates over a broad temperature range, ensuring reliable performance across various environmental conditions.

Applications

The ESDS314DBVR is versatile and can be used in a variety of applications where ESD protection is critical. Some common applications include:

  • USB interfaces
  • HDMI ports
  • DisplayPort connections
  • Thunderbolt ports
  • Antenna connections
  • High-speed data lines in consumer electronics

Conclusion

In conclusion, the Texas Instruments ESDS314DBVR is a state-of-the-art ESD protection device that offers excellent performance in a compact package. Its low capacitance, high ESD protection level, and low clamping voltage make it an essential component for designers looking to enhance the durability and longevity of their electronic products. Whether it's for personal devices or industrial applications, the ESDS314DBVR stands as a reliable safeguard against the unpredictable nature of electrostatic discharge.
