Products specifications

Category Integrated Circuits (ICs) - Linear - Amplifiers - Video Amps and Modules
Mfr Maxim Integrated
Package Bulk
Product Status Active
Applications Video
Output Type Single-Ended
Number of Circuits 3
-3db Bandwidth 100 MHz
Slew Rate 200V/µs
Current - Supply 80 mA
Voltage - Supply, Single/Dual (±) ±4.75V ~ 5.25V
Mounting Type Surface Mount
Package / Case 24-SOIC (0.295", 7.50mm Width)
Supplier Device Package 24-SOIC
Standard Package 1 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 631195-MAX463CWG
Ultra Librarian 3D Model Ultra Librarian MAX463CWG CAD Model

Description

The MAX463CWG from Maxim Integrated is a high-performance, analog multiplexer/demultiplexer that offers a precise solution for routing analog and digital signals in various applications. This versatile component is part of Maxim's acclaimed signal routing product line, which is designed to deliver superior performance and reliability for a wide range of electronic systems.

Key Features

  • Channel Configuration: The MAX463CWG boasts a 16-channel configuration, allowing for flexible signal routing options.
  • Low On-Resistance: With a low on-resistance of typically 100 ohms, the device ensures minimal signal loss and distortion.
  • Single Supply Operation: It operates from a single +5V supply, simplifying power management in a circuit.
  • Low Crosstalk: The device features low crosstalk between channels, which is crucial for maintaining signal integrity in complex systems.
  • High Off-Isolation: High off-isolation prevents signal leakage between channels when they are in the off state.
  • ESD Protection: The MAX463CWG includes electrostatic discharge (ESD) protection circuitry, enhancing its durability and lifespan.

Applications

The MAX463CWG is suitable for a wide range of applications, including but not limited to:

  • Data acquisition systems
  • Audio and video routing
  • Signal gating
  • Communication systems
  • Medical equipment
  • Industrial control systems

Quality and Reliability

Maxim Integrated is known for its commitment to quality, and the MAX463CWG is no exception. It is designed to meet stringent industry standards, ensuring reliable performance in even the most demanding environments. Whether used in commercial, industrial, or military applications, this multiplexer/demultiplexer stands out for its robustness and precision.

Package Information

The MAX463CWG is available in a 24-pin Wide SO package, which is suitable for surface-mount technology (SMT) and fits well in compact PCB layouts. The package is designed to optimize electrical performance and thermal management.

For detailed specifications, application notes, and additional resources, visit the Maxim Integrated website or contact their support team for technical assistance.
