Products specifications

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 100mV
Data Rate 500kbps
Supply Voltage - Operating 3 V to 3.6 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 1067221-MAX3075EESA+T
Family Name MAX3075E
Introduction Date October 01, 2002
ECCN EAR99
Country of Origin Malaysia, Philippines, Thailand
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX3075EESA+T CAD Model

Description

Maxim Integrated MAX3075EESA+T RS-485/RS-422 Transceiver

The MAX3075EESA+T from Maxim Integrated is a high-performance, half-duplex transceiver designed for RS-485 and RS-422 communication applications. This device is particularly suitable for long-distance and high-speed data transmission over twisted pair cables. It operates from a single 3.3V supply, making it ideal for systems that require minimal power consumption and a reduced level of electromagnetic interference (EMI).

The MAX3075EESA+T features a slew-rate-limited driver that minimizes EMI and reduces reflections caused by improperly terminated cables, thus ensuring reliable data transmission even over longer distances. The device supports data rates up to 250kbps, making it versatile for various communication protocols and network configurations.

With its fail-safe feature, the receiver ensures a logic-high output if the input is open circuit, shorted, or connected to a terminated transmission line without any signal present. This functionality enhances the robustness of the communication system by providing additional protection against fault conditions.

The transceiver comes in a compact 8-pin NSOIC package, which is highly beneficial for space-constrained applications. The MAX3075EESA+T is also characterized for operation from -40°C to +85°C, allowing it to perform reliably in a wide range of industrial environments.

Additional features of the MAX3075EESA+T include thermal shutdown protection, which prevents damage to the device in the event of excessive power dissipation, and a low quiescent current, which makes it suitable for battery-powered and energy-efficient systems. The device's integrated protection against electrostatic discharge (ESD) exceeds ±15kV using the Human Body Model, providing a high level of robustness for equipment subjected to harsh electrical environments.

Overall, the MAX3075EESA+T is an excellent choice for designers looking for a reliable, low-power transceiver for RS-485/RS-422 communication networks. With its advanced features and Maxim Integrated's reputation for quality, this transceiver is well-suited for industrial control systems, networked security systems, and any application requiring robust data communication.
